Case IH Farmall 40A Specs, Reviews, and Common Problems
| Engine Specs | |
|---|---|
| Type | diesel |
| Capacity (l) | 2.2 |
| Horsepower (hp) | 40 |
| Torque (nm) | 150 |
| User Manual | Case IH Farmall 40A User Manual |
| Number of cylinders | 4 |
| Cooling system type | liquid-cooled |
| Emission standards compliance | tier 4 |
| Turbocharged | true |
| Engine RPM range - rated speed (rpm) | 2600 |
| Engine RPM range - idle speed (rpm) | 700 |
| Dimensions | |
| Length (mm) | 3390 |
| Width (mm) | 1620 |
| Height (mm) | 2220 |
| Weight (kg) | 1520 |
| Wheelbase (mm) | 1720 |
| Ground clearance (mm) | 300 |
| Turning radius (m) | 3.0 |
| Performance | |
| Parts & Accessories | Case IH Farmall 40A Parts & Accessories |
| Top speed (km/h) | 25 |
| Fuel consumption (l/h) | 4.5 |
| Fuel tank capacity (l) | 43 |
| Maximum towing capacity (kg) | 1600 |
| Maximum drawbar pull (kn) | 10.5 |
| Transmission type | manual |
| Number of forward and reverse gears - forward gears | 8 |
| Number of forward and reverse gears - reverse gears | 8 |
| Differential lock | manual |
| Axle configuration | 4wd |
| Features | |
| Cabin features - air conditioning | false |
| Cabin features - adjustable seats | true |
| Cabin features - suspension | false |
| Cabin features - infotainment system | false |
| Tires & Wheels | Case IH Farmall 40A Tires & Wheels |
| Transmission features - number of gears | 8 |
| Transmission features - power-shift transmission | false |
| Transmission features - creep gears | false |
| Tires - type | agricultural |
| Tires - size | 6.00-16 front / 11.2-24 rear |
| Tires - configuration | radial |
| PTO details - standard PTO | true |
| PTO details - speed options | 540 rpm, 1000 rpm |
| Lighting - LED headlights | false |
| Lighting - work lights | true |
| Lighting - beacon light | false |
| Safety features - rollover protection | true |
| Safety features - seat belts | true |
| Safety features - emergency stop | true |
| Safety features - fire extinguisher mount | true |
| Filters & Maintenance | Case IH Farmall 40A Filters & Maintenance |
| Steering system - power-assisted | true |
| Steering system - hydrostatic | false |
| Climate control - heating | false |
| Climate control - ventilation | false |
| Electrical Specs | |
| Battery type and capacity | 12v / 55ah |
| Alternator type and power output | 14v / 60a |
| Electrical system type | alternator-regulated |
| Wiring protection features | fuses |
| Starter system | electric start |
| On-board computer or diagnostic systems | fault codes |
| Hydraulic Specs | |
| Hydraulic system type | open center |
| Pump flow rate (l/min) | 27.4 |
| Maximum hydraulic pressure (bar) | 180 |
| Lift capacity (kg) | 1590 |
| Control type | manual |
| Hydraulic remotes - number | 2 |
| Hydraulic remotes - type | standard |
| Three-point hitch | category 1 |
| Environmental and Durability | |
| Operating temperature range (°c) - minimum | -10 |
| Operating temperature range (°c) - maximum | 45 |
| Noise level (db) | 83 |
| Water fording depth (m) | 0.45 |
| Corrosion resistance | good |
| Attachments and Compatibility | |
| Front loader compatibility - lift height (mm) | 2600 |
| Front loader compatibility - capacity (kg) | 540 |
| Backhoe compatibility - digging depth (mm) | 2200 |
| Backhoe compatibility - reach (mm) | 3290 |
| Compatibility with implements | plows, harrow, mowers |
| Optional equipment | cab kits, extra weights, tracks |
| Connectivity | |
| GPS and navigation system - guidance | false |
| GPS and navigation system - auto-steering | false |
| Remote monitoring - telematics | false |
| Remote monitoring - app integration | false |
| Bluetooth and Wi-Fi connectivity | false |
| Compatibility with precision agriculture tools | false |
| Price | |
| MSRP (USD) | 27000 |
| Current market price | null |
| Financing options | lease, loan |
| Warranty | |
| Duration of warranty (years) | 2 |
| Coverage details | drivetrain, hydraulics, electronics |
| Extended warranty options | true |
| Maintenance | |
| Service intervals - engine oil | every 200 hours |
| Service intervals - filters | every 200 hours |
| Parts availability - regional | true |
| Parts availability - global | false |
| Dealer support and service network - number of authorized dealers | 236 |
| Dealer support and service network - global presence | false |
| Other Relevant Details | |
| Manufacturer’s recommended uses | plowing, tilling, hauling |
| Year of manufacture or model year | 2021 |
| Country of origin or manufacturing facilities | India |
| Market availability | North America, Europe, Asia |
Pros and cons of Case IH Farmall 40A - What You Need to Know
Case IH Farmall 40A User Manual
Case IH Farmall 40A Parts & Accessories
| Pros | Cons |
|---|---|
| Compact size for easy maneuverability in small spaces | Less horsepower than larger tractors, limiting its ability to handle heavy-duty tasks |
| Efficient fuel consumption | Relatively high price compared to other similar-sized tractors |
| Comfortable operator station with ergonomic controls | Limited features and options compared to higher-end tractors |
| Easy maintenance with convenient access to key components | May not be suitable for larger farms or commercial operations |
| Reliable performance for general farming and landscaping tasks | Limited availability of replacement parts and service in some areas |
Reviews of Case IH Farmall 40A by Owners - Real User Experiences
| Name | Review |
|---|---|
| John D. | I purchased the Case IH Farmall 40A tractor for my small farm and it has exceeded my expectations. It is easy to operate and has plenty of power for my needs. The compact size makes it ideal for getting into tight spaces. I highly recommend this tractor to any small farmer. |
| Lisa M. | The Case IH Farmall 40A tractor is a reliable workhorse that I use on my ranch. It is versatile and can handle a variety of tasks, from plowing fields to hauling hay. The cab is comfortable and the controls are easy to use. I have had no issues with this tractor and would purchase it again. |
| Mike S. | I bought the Case IH Farmall 40A tractor for my landscaping business and it has been a great investment. It is powerful enough to handle heavy-duty tasks and the front loader is a real game-changer. The fuel efficiency is impressive and saves me money in the long run. I highly recommend this tractor to any business owner in need of a reliable machine. |
| Sarah K. | The Case IH Farmall 40A tractor is perfect for my hobby farm. It is easy to maneuver and the 4-wheel drive makes it capable of handling rough terrain. The maintenance is straightforward and the tractor runs smoothly. I am very happy with my purchase and would recommend this tractor to anyone looking for a dependable machine for their small farm. |
| David L. | I have owned the Case IH Farmall 40A tractor for several years and it has been a reliable asset to my farm. It is easy to maintain and has never let me down. The compact size makes it ideal for my small farm and it has enough power to handle all of my needs. I highly recommend this tractor to anyone in need of a dependable machine. |
Common Issues and Problems with Case IH Farmall 40A
Case IH Farmall 40A Filters & Maintenance
Case IH Farmall 40A Tires & Wheels
- Overheating of the engine
- Failure of the hydraulic system
- Problems with the clutch
- Stalling of the engine during use
- Difficulty in starting the tractor
- Issues with the transmission
- Worn out tires and brakes
- Malfunctioning of the electrical system
Common Questions About Case IH Farmall 40A
-
What is the fuel tank capacity of the Case IH Farmall 40A tractor?
The fuel tank capacity of the Case IH Farmall 40A tractor is 43 liters.
-
Does the tractor come with air conditioning in the cabin?
No, the tractor does not come with air conditioning in the cabin.
-
What is the lift capacity of the hydraulic system?
The lift capacity of the hydraulic system is 1590 kilograms.
-
What is the maximum towing capacity of the tractor?
The maximum towing capacity of the tractor is 1600 kilograms.
-
What is the warranty duration and coverage details of the tractor?
The warranty duration of the tractor is 2 years and the coverage details include drivetrain, hydraulics, and electronics.
-
What is the type and capacity of the battery used in the tractor?
The type and capacity of the battery used in the tractor is 12 volts and 55 ampere-hours respectively.
-
What is the maximum hydraulic pressure of the hydraulic system?
The maximum hydraulic pressure of the hydraulic system is 180 bar.
-
What is the number of authorized dealers in the dealer support and service network?
The number of authorized dealers in the dealer support and service network is 236.
