Swaraj 724 XM Specs, Reviews, and Common Problems
| Engine Specs | |
|---|---|
| Type | diesel |
| Capacity | 3136 cc |
| Horsepower | 25.5 hp |
| Torque | 83.14 nm |
| User Manual | Swaraj 724 XM User Manual |
| Number of Cylinders | 3 |
| Cooling System Type | water-cooled |
| Emission Standards Compliance | bs4 |
| Turbocharged or Naturally Aspirated | naturally aspirated |
| Engine RPM Range - Rated Speed | 2000 rpm |
| Engine RPM Range - Idle Speed | 850-900 rpm |
| Dimensions | |
| Length | 3440 mm |
| Width | 1715 mm |
| Height | 2200 mm |
| Weight | 1800 kg |
| Wheelbase | 1950 mm |
| Ground Clearance | 360 mm |
| Turning Radius | 3000 mm |
| Performance | |
| Parts & Accessories | Swaraj 724 XM Parts & Accessories |
| Top Speed | 24.6 km/h |
| Fuel Consumption | 5.6 liters per hour |
| Fuel Tank Capacity | 60 liters |
| Maximum Towing Capacity | 2000 kg |
| Maximum Drawbar Pull | 10.8 kn |
| Transmission Type | constant mesh / sliding mesh |
| Number of Forward and Reverse Gears | 8 forward + 2 reverse |
| Differential Lock | yes, manual |
| Axle Configuration | 2wd |
| Features | |
| Cabin Features - Air Conditioning | no |
| Cabin Features - Adjustable Seats | yes |
| Cabin Features - Suspension | mechanical |
| Cabin Features - Infotainment System | no |
| Transmission Features - Number of Gears | 8 forward + 2 reverse |
| Tires & Wheels | Swaraj 724 XM Tires & Wheels |
| Transmission Features - Power-Shift Transmission | no |
| Transmission Features - Creep Gears | no |
| Tires - Tire Type | tubeless |
| Tires - Size - Front | 6.00 x 16 |
| Tires - Size - Rear | 13.6 x 28 |
| Tires - Configuration | 4-wheel configuration |
| PTO Details - Standard PTO | 540 rpm |
| PTO Details - Speed Options | no |
| Lighting - LED Headlights | no |
| Lighting - Work Lights | yes |
| Lighting - Beacon Light | yes |
| Safety Features - Rollover Protection | yes |
| Safety Features - Seat Belts | yes |
| Safety Features - Emergency Stop | yes |
| Safety Features - Fire Extinguisher Mount | yes |
| Filters & Maintenance | Swaraj 724 XM Filters & Maintenance |
| Steering System - Power-Assisted | no |
| Steering System - Hydrostatic | no |
| Climate Control - Heating | no |
| Climate Control - Ventilation | no |
| Electrical Specs | |
| Battery Type and Capacity | 12v / 88 ah |
| Alternator Type and Power Output | 12v / 36a |
| Electrical System Type | 12v, alternator-regulated |
| Wiring Protection Features | fuses |
| Starter System | electric start |
| On-Board Computer or Diagnostic Systems | no |
| Hydraulic Specs | |
| Hydraulic System Type | open center |
| Pump Flow Rate | 19.8 lpm |
| Maximum Hydraulic Pressure | 170 bar |
| Lift Capacity | 1000 kg |
| Control Type | manual |
| Hydraulic Remotes | 1 double acting |
| Three-Point Hitch | category i |
| Environmental and Durability | |
| Operating Temperature Range | 0-50°c |
| Noise Level | 90 db |
| Water Fordind Depth | not specified |
| Corrosion Resistance | not specified |
| Attachments and Compatibility | |
| Front Loader Compatibility - Lift Height | 2.1 meters |
| Front Loader Compatibility - Capacity | 750 kg |
| Backhoe Compatibility - Digging Depth | not compatible |
| Backhoe Compatibility - Reach | not compatible |
| Compatibility with Implements - Plows | yes |
| Compatibility with Implements - Harrows | yes |
| Compatibility with Implements - Mowers | yes |
| Optional Equipment - Cab Kits | yes |
| Optional Equipment - Extra Weights | yes |
| Optional Equipment - Tracks | no |
| Connectivity | |
| GPS and Navigation System | no |
| Remote Monitoring | no |
| Bluetooth and Wi-Fi Connectivity | no |
| Compatibility with Precision Agriculture Tools | no |
| Price | |
| MSRP | inr 6.20 lakhs |
| Current Market Price | varies by region |
| Financing Options | available |
| Warranty | |
| Duration of Warranty | 2 years |
| Coverage Details - Drivetrain | yes |
| Coverage Details - Hydraulics | yes |
| Coverage Details - Electronics | no |
| Extended Warranty Options | not specified |
| Maintenance | |
| Service Intervals - Engine Oil | 150 hours |
| Service Intervals - Filters | not specified |
| Parts Availability | global |
| Dealer Support and Service Network | available |
| Other Relevant Details | |
| Manufacturer's Recommended Uses - Plowing | yes |
| Manufacturer's Recommended Uses - Tilling | yes |
| Manufacturer's Recommended Uses - Hauling | yes |
| Year of Manufacture or Model Year | 2019 |
| Country of Origin or Manufacturing Facilities | india |
| Market Availability | global |
Pros and cons of Swaraj 724 XM - What You Need to Know
Swaraj 724 XM User Manual
Swaraj 724 XM Parts & Accessories
| Pros | Cons |
|---|---|
| Powerful engine | Can be expensive |
| Good fuel efficiency | May not be suitable for large farms |
| Robust and durable | May require frequent maintenance |
| Comfortable cabin | May not have as many features as other tractors in its class |
| Easy to operate | May not have the highest resale value |
Reviews of Swaraj 724 XM by Owners - Real User Experiences
| Name | Review |
|---|---|
| John | I have been using the Swaraj 724 XM tractor for my farm for over a year and I am extremely satisfied with its performance. It is highly efficient and has helped me save a lot of time and effort in my farming activities. The tractor is also very easy to maintain and has a low cost of ownership. I would highly recommend this tractor to any farmer looking for a reliable and efficient machine. |
| Mary | The Swaraj 724 XM tractor has been a great addition to my farm. It is very powerful and has helped me plow my fields with ease. The tractor is also very comfortable to operate and has a spacious cabin that allows for easy movement. The only downside is that it can be a bit noisy, but that is a minor issue compared to its overall performance. |
| David | I have used several tractors in the past, but the Swaraj 724 XM is by far the best. It is very durable and has a robust build that can withstand tough farming conditions. The tractor also has a high ground clearance, which makes it easy to navigate through rough terrain. Overall, I am very happy with my purchase and would recommend this tractor to anyone looking for a reliable and sturdy machine. |
| Jane | The Swaraj 724 XM tractor has exceeded my expectations. It is very versatile and can be used for a variety of farming activities, from plowing to harvesting. The tractor also has a high fuel efficiency, which has helped me save a lot of money on fuel costs. I would definitely recommend this tractor to any farmer looking for a reliable and efficient machine. |
| Tom | I recently purchased the Swaraj 724 XM tractor for my farm and I am very impressed with its performance. The tractor is very easy to operate and has a smooth transmission that allows for easy gear shifting. The tractor also has a good turning radius, which makes it easy to maneuver in tight spaces. Overall, I am very satisfied with my purchase and would recommend this tractor to anyone looking for a reliable and easy-to-use machine. |
Common Issues and Problems with Swaraj 724 XM
Swaraj 724 XM Filters & Maintenance
Swaraj 724 XM Tires & Wheels
- The engine overheats after prolonged use, leading to reduced efficiency and potential breakdown.
- The clutch system tends to wear out quickly, resulting in difficulty shifting gears and reduced pulling power.
- The hydraulic system often fails, causing the tractor's lifting capacity to decrease and rendering it ineffective for heavy-duty work.
- The steering system is prone to developing issues, such as stiffness or looseness, which can make it challenging to control the tractor.
- The electrical system, including the battery and alternator, frequently malfunctions, causing the tractor to fail to start or stop running unexpectedly.
- The transmission system is not very durable, and the gears tend to wear out quickly, leading to reduced power and performance.
- The fuel system can become clogged or blocked, leading to poor fuel efficiency, reduced power, and potential engine damage.
- The brakes can wear out quickly or become unresponsive, leading to safety concerns while driving the tractor.
Common Questions About Swaraj 724 XM
-
What is the engine capacity of the Swaraj 724 XM tractor?
The engine capacity of the Swaraj 724 XM tractor is 3136 cc.
-
What is the maximum towing capacity of the Swaraj 724 XM tractor?
The maximum towing capacity of the Swaraj 724 XM tractor is 2000 kg.
-
Does the Swaraj 724 XM tractor have air conditioning in the cabin?
No, the Swaraj 724 XM tractor does not have air conditioning in the cabin.
-
What is the maximum lift capacity of the three-point hitch in the Swaraj 724 XM tractor?
The maximum lift capacity of the three-point hitch in the Swaraj 724 XM tractor is 1000 kg.
-
What is the MSRP of the Swaraj 724 XM tractor?
The MSRP of the Swaraj 724 XM tractor is INR 6.20 lakhs.
-
What is the duration of the warranty for the Swaraj 724 XM tractor?
The duration of the warranty for the Swaraj 724 XM tractor is 2 years.
-
What is the maximum hydraulic pressure of the Swaraj 724 XM tractor?
The maximum hydraulic pressure of the Swaraj 724 XM tractor is 170 bar.
-
Does the Swaraj 724 XM tractor come with LED headlights?
No, the Swaraj 724 XM tractor does not come with LED headlights.
